Product Features:
1. Full open process parameters package, easy to secondary development;
2. Feed powder, efficient two-way laying powder;
3. Precision adjustable scraper, to ensure the powder laying accuracy;
4. Six vibrator layout, suitable for batch efficient printing;
Equipment parameters:
Equipment model | HANS M410 |
Size of equipment | 2300mm×1300mm×2600mm |
Max building size | 450mm×350mm×400mm |
Laser Power | 500W*2/4/6 |
Laser beam quality | M² < 1.1 |
Laser length | 1060nm to 1080nm |
Spot diameter | 90 microns or less |
Layer thickness | 20μm to 100μm |
Optical system | F-theta-lens, scanning galvanometer |
Scan Speed | ≤10m/s |
Oxygen concentration | ≤100ppm |
Powder feeding mode | Top Feeding Powder |
Shielding gas | Nitrogen/Argon |
Software | Magics+BP |
Machine mess | < 4000Kg |
Working power/ Power consumption | 380V±10%, 72A/40KW |
Applicable material | Stainless steel, die steel, cobalt-based alloy, superalloy, titanium alloy, aluminum alloy, etc |
