Product features:
1.Fully self-developed integrated design for high equipment integration.
2.Long-life eco-friendly filter cartridges for safety and sustainability.
3.Optional red/green laser to meet diverse application needs.
4.Integrated smart monitoring module for real-time inspection of melt pools, morphology, and powder spreading.
5.Equipped with standard and high-temperature small build cylinders to facilitate new material process development.
6.Supports support-free or minimal-support printing, breaking through design limitations.
Product parameters:
Size of device: | 887×1370×2060mm |
Max building size: | Φ190×200mm |
Workpiece dimensional accuracy： | ＜100mm,±0.05mm;＞100mm,±0.1% |
Sintering plate heating temperature： | ≤ 200°C |
Laser Power： | 500W×1，Optional with red or green laser |
Laser length： | Red laser：1060~1080nm |
Spot diameter： | 20-55μm |
Layer thickness： | 0.02~0.2mm |
Scanning speed: | ≤ 10m/s |
Oxygen concentration： | ≤ 100ppm |
Powder feeding mode： | Bottom Powder Feeding |
Shielding gas： | nitrogen/argon(N₂/Ar) |
Machine mess（excluding accessories）： | 800 Kg |
Power supply： | Red laser：AC 220V Ph/N/PE，50Hz、60Hz，40A |
Applicable material： | Pure Copper、Copper Alloy、 Stainless Steel、Titanium Alloy、Aluminum Alloy、 Superalloy |
